Camera |
Image Sensor | 1/3" Progressive Scan CMOS Sensor |
Resolution | 4MP |
Effective Pixels | 2560(H)*1440(V) |
Compression | H.264/H.264+/H.265/H.265+/JPEG/AVI/MJPEG |
Audio Compression | G711A/U,AAC |
TV System | PAL/NTSC |
Electronic Shutter Time | Auto: 1/3-1/100000Sec |
Minimun Illumination | Color: 0.03 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
S/N Ratio | 60dB |
Scanning System | Progressive |
Video Output | Network |
Reset Button | Optional |
Lens |
Focal Length & FOV | 2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122° 3.6 mm, horizontal FOV 81°, vertical FOV 41°, diagonal FOV 96° 6 mm, horizontal FOV 50°, vertical FOV 27°, diagonal FOV 59° |
Lens Type | Fixed focal lens, 2.8, 3.6, and 6 mm optional |
Focus Control | Fixed |
Aperture | F1.6 |
Pixels | 4MP |
Night Vision |
Infrared LED | 42µ x 2PCS |
Infrared Distance | 25M |
IR Status | Auto Control |
IR Power On | Smart, Manual & Timed mode |
Network |
Ethernet | RJ-45 (10/100Base-T) |
Wireless | N/A |
Protocol | TCP/IP,IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP ,PPPoE, NTP, SMTP, UDP,Qos,802.1x |
ONVIF | Support ONVIF 19.12(Profile S/T/G) |
P2P | YES |
POE | Internal, Support IEEE 802.3af |
Video Delay | 0.3S (Within the Lan) |
Main Stream 1 | 2688*1512@25fps |
Main Stream 2 | 2560*1440@30fps |
Main Stream 3 | 1920*1080@30fps 1280*720@30fps |
Sub Stream 1 | 1280*720@30fps |
Sub Stream 2 | 720*480@30fps |
Sub Stream 3 | N/A |
Tri Stream | N/A |
IE Brower | IE8-11, Google Chrome, Firefox , Mac Safari |
Smart Phone | iPhone, Android |
AI Function |
Intelligent Analysis | Intrusion Detetion,motion detection based on human detection |
Camera Features |
Day/Night | Color/ B&W (IR-CUT ) |
Image Config | Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control), Video Tampering, HLC, Distortion |
Full Color | N/A |
Corridor Pattern | Support |
Defog Mode | Support |
ROI | Support |
BLC | Support |
WDR | DWDR |
Motion Detection | Support(support enable the detection based on human movement only) |
Privacy Masking | 3 Rectangular Zone |
Recording Mode | NVR/CMS/Web |
Language | Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands,Czech, Vietnamese |
Interface |
Audio | Optional 1 Built-in MIC |
Alarm | N/A |
SD Card Slot | Optional Internal, Support Max 512GB |
RS485 | N/A |
General |
Housing | Front Cover: Metal, Back Cover: Plastic ,IP67 |
Anti-cut Bracket | No |
IR Cut Filter | YES |
Operation Temperature | -20℃ ~ +60℃ RH95% Max |
Storage Temperature | -20℃ ~ +60℃ RH95% Max |
Power Source | DC12V±10%, 700mA |
Dimension | 176.6(W)x67(H)x69.8(D)mm |
Weight | 370g |
