| SPECIFICATION | |
| Model NO. | FK08GR |
| System | |
| Main Processor | RV1109, Dual ARM Cortex-A7, NPU 1.2T |
| Operating System | Embedded LINUX |
| RAM | DDR3 1GB |
| ROM | EMMC 16GB |
| Screen | |
| Dimensions | 10.1 inch IPS HD LCD screen |
| Resolution | 800*1280 |
| Camera | |
| Type | 2MP camera |
| Sensor | 1/2.9" GC2053 |
| Resolution | NIR 1280*720@25fps |
| Lens | 4.5mm |
| Camera | |
| Type | Daily camera |
| Sensor | 1/2.9" GC2093 |
| Resolution | Color 1920*1080@25fps |
| Lens | 4.5mm |
| Face recognition | |
| Detection Function | Face Dection, Face Comparison, Mask Detection, Living Body Detection, Face Comparison(With Mask) |
| Face Recognition Distance | 0.5-2m |
| Face Database Capacity | Max support 30,000 faces |
| Face Posture | Vertical 61°, horizontal 36° |
| Occlusion | Ordinary glasses and short fringe have no effect on recognition. |
| Expression | Under normal circumstances, slight expressions do not affect recognition. |
| Response Speed | About 200ms |
| Face Exposure | Support |
| Local Storage | Support storage of 50,000 records |
| Recognition Area | Full screen recognition |
| Upload Method | TCP, HTTP, MQTT |
| Network Functions | |
| Network Protocol | IPv4, TCP/IP, HTTP, MQTT, RTSP, SMTP, NTP |
| Interface Protocol | Private protocol |
| Security Mode | Authorized password |
| Event Linkage | Voice broadcast, Abnormal event upload to the platform, Alarm Output |
| System Upgrade | Support remote upgrade |
| Accessories | |
| Supplementary Light | IR light, LED white light |
| Identification Module | / |
| Audio Out | Built in Speaker support voice broadcast after successful recognition |
| Wi-Fi | / |
| Bluetooth | / |
| Card Reader | Bulit in IC card reader, Support Mifare1 IC card |
| 4G | / |
| Alarm Indicator Light | Abnormal red light, Normal green light |
| Interface | |
| Network Interface | RJ45 10M/100M Network Adaptation |
| Alarm Input | / |
| Alarm Output | Support 1 channel |
| Relay Output | Support |
| RS485 | Support |
| Wiegand Interface | Support Wiegand 26, 34 protocols |
| USB | 1*USB 2.0 |
| TF Card Slot | / |
| HDMI | / |
| Reset Key | Support |
| Anti-disassembly Switch | / |
| General | |
| Housing | Aluminum alloy, Ultra-white tempered glass panel |
| Operating Temperature | -10 ° C ~ 50 ° C |
| Working Humidity | 10% -90% Non-condensing |
| Storage Temperature | -20 ° C ~ 50 ° C |
| Storage Humidity | 5% -95% Non-condensing |
| Protection Level | / |
| Power Supply | DC12V, 2A |
| Power Dissipation (maximum) | 18 W |
| Dimensions (mm) | Column Bracket Model:363.5(L)*132(W)*92(H)mm, Wall Bracket Model:258.5x(L)*132(W)*31(H)mm |
| Bracket Size (mm) | Column Bracket:202.5mm(Bracket fixing hole size D=35mm) |
| Installation Method | Gate machine Installation/Column Installation/Wall Installation |
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
