CMSCKL800
8MP Outdoor Infrared Fixed Conch Network Camera
  • •    High quality imaging with 8MP resolution;
  • •    1/2.8"SONY Starvis Back-illuminated CMOS sensor;
  • •    Support H.264/H.265/H.264+/H.265+/JPEG/AVI Compression ;
  • •    Minimum Illumination:0.05 Lux,Infrared Distance:25m;
  • •    Support WDR;
  • •    Housing: Metal (Ring Plastic) , IP67
  • Specification
  • Accessories
  • Download
    Camera
    Image Sensor1/2.8" SONY Starvis Back-illuminated CMOS sensor
    Resolution8MP
    Effective Pixels3864(H)*2192(V)
    Compression H.264/H.265/H.264+/H.265+/JPEG/AVI
    Audio CompressionG711A/U,AAC
    TV SystemPAL/NTSC
    Electronic Shutter TimeAuto: 1/3-1/100000Sec
    Minimun IlluminationColor: 0.05 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
    S/N Ratio60dB
    Scanning SystemProgressive
    Video OutputNetwork
    Reset ButtonOptional
    Lens
    Focal Length & FOV2.8 mm, horizontal FOV 96°, vertical FOV 52°, diagonal FOV 114°
    4 mm, horizontal FOV 84°, vertical FOV 48°, diagonal FOV 97°
    6 mm, horizontal FOV 53°, vertical FOV 30°, diagonal FOV 60°
    Lens TypeFixed focal lens, 2.8, 4, and 6 mm optional
    Focus ControlFixed
    ApertureF1.6
    Pixels8MP
    Night Vision
    Supplement Light42µ x 2PCS
    Supplement Light Distance25M
    Supplement Light StatusAuto Control
    Supplement Light Power OnManual & Timed mode
    Network
    EthernetRJ-45 (10/100Base-T)
    WirelessN/A
    ProtocolTCP/IP,IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP,  SMTP, UDP, SNMP,Qos,802.1x
    ONVIFSupport ONVIF 19.12(Profile S/T/G)
    P2PYES
    POEInternal, Support IEEE 802.3af
    Video Delay0.3S (Within the Lan)
    Main Stream 13840*2160@20fps
    Main Stream 22560*1440@20fps
    Main Stream 31920*1080@20fps
    1280*720@20fps
    Sub Stream 11280*720@20fps
    Sub Stream 2720*480@20fps
    Sub Stream 3N/A
    Tri StreamN/A
    IE Brower IE8-11, Google Chrome, Firefox , Mac Safari
    Smart PhoneiPhone, Android
    AI Function
    Intelligent AnalysisIntrusion Detetion(based on human and Vehicle Detection), Line Cross Detetion(based on human and Vehicle Detection), Loiter Detetion(based on human detection), People Gather Detecion(based on human detection), Motion detection based on human detection, Enter Area(based on human and Vehicle Detection), Leave Area(based on human and vehicle Detection)
    Camera Features
    Day/NightColor/ B&W (IR-CUT )
    Image ConfigSaturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, Anti Flicker, Video Tampering,HLC
    Full ColorN/A
    Corridor PatternSupport
    Defog  ModeN/A
    ROISupport
    BLCSupport
    WDRSupport
    Motion DetectionSupport(support enable the detection based on human movement only)
    Privacy  Masking3 Rectangular Zone
    Recording ModeNVR/CMS/Web
    LanguageChinese Simplified, Chinese Traditional, English, Russian, Korean, Polish, French, Japanese, Spanish, Portuguese, Italian, Hebrew, Ukrainian,  Arabic, Vietnamese, Thai, Hungarian
    Interface
    AudioOptional 1 Built-in MIC
    AlarmN/A
    SD Card SlotOptional Internal, Support Max 1TB
    RS485N/A
    General
    HousingMetal (Ring Plastic) , IP67
    Anti-cut BracketNO
    IR Cut FilterYES
    Operation Temperature-20℃ ~ +60℃ RH95% Max
    Storage Temperature-20℃ ~ +60℃ RH95% Max
    Power SourceDC12V±10%, 700mA
    Dimensionφ126.8 x 93.8(H) mm
    Weight630g

    *Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
