LMEMTCSS4002W
4MP Miniature IP Cameras
  • •    1/2.8"SONY Starvis Back-illuminated CMOS Sensor;
  • •    Support H.264/H.264+/H.265/H.265+/JPEG/AVI/MJPEG Compression ;
  • •    Support WIFI: No obstacles 300m Max. ;
  • •    Support SD Card Slot (Max 512GB);
  • •    Support WDR: HDR: 120dB;
  • •    Housing: Metal
  • Specification
  • Accessories
  • Download
    Camera
    Image Sensor1/2.8" SONY Starvis Back-illuminated CMOS Sensor
    Resolution4MP
    Effective Pixels2616 (H)*1964 (V)
    Compression H.264/H.264+/H.265/H.265+/JPEG/AVI/MJPEG
    Audio CompressionG.711A/U, AAC
    TV SystemPAL/NTSC
    Electronic Shutter TimeAuto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec
    Minimun IlluminationColor: 0.003 lux@F1.6,AGC ON; B/W :0 lux with IR
    S/N Ratio≥52dB
    Scanning SystemProgressive
    Video OutputNetwork
    Reset ButtonSupport
    LENS Type
    Focus Length2.8mm /106°(F1.6)
    Focus ControlFixed
    Lens TypeFixed
    Pixels2MP
    Night Vision
    Infrared LEDN/A
    Infrared DistanceN/A
    IR StatusN/A
    IR Power OnN/A
    Network
    EthernetRJ-45 (10/100Base-T)
    ProtocolTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, SMTP, UDP
    ONVIFSupport ONVIF 2.4(Profile S)
    P2PYES, Support QR Code
    POEInternal, Support IEEE 802.3af
    Video Delay0.3S (Within the Lan)
    Main Stream 12560*1440@30fp
    Main Stream 21920*1080@30fps
    Main Stream 31280*720@30fps
    Sub Stream 1720*480@30fps
    Sub Stream 2352*288@30fps
    Sub Stream 3N/A
    Tri Stream1280*720@30fps
    720*480@30fps
    352*288@30fps
    IE Brower IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53), Mac Safari(lower than version 12)
    Smart PhoneiPhone, Android
    Wireless
    Antena7dbi
    HotspotN/A
    Wi-FiWi-Fi(IEEE802.11b/g/n),2.4Ghz
    WIFI RangeNo obstacles 300m Max.
    AI Function
    Intelligent AnalysisN/A
    Camera
    Day/NightColor
    Image ConfigSaturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control), Video Tampering, HLC
    Corridor PatternSupport
    ROISupport
    Defog  ModeSupport
    BLCSupport
    WDRHDR: 120dB
    Motion DetectionSupport
    Privacy  Masking3 Rectangular Zone
    Recording ModeNVR/VMS/Web/SD Card
    LanguageChinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands,Czech, Vietnamese
    Interface
    AudioAudio IN/OUT(3.5mm audio interface)
    Alarm1ch Alarm In/1ch Alarm Out
    SD Card SlotSupport  512G Micro SD Card Slot
    RS485N/A
    General
    HousingMetal
    Anti-cut BracketNO
    IR Cut FilterNO
    Operation Temperature-20℃ ~ +60℃ RH95% Max
    Storage Temperature-20℃ ~ +60℃ RH95% Max
    Power SourceDC12V±10%, 350mA
    Dimension104(L) x 78(W) x25.8(H)mm
    Weight810g

    *Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
